Designing a Payment System: The Weight of Code That Moves Money

Sleepless at 3 AM

A user sent me an email. They'd been charged twice. A $50 product, but $100 had left their card. I dug through the logs. One order. Two payment records. They'd clicked "Pay Now" twice, and my code had accepted both clicks.

I couldn't sleep that night. While processing the refund, it hit me. Integrating a payment API is just the beginning. Code that moves money is different. Even if click events fire twice, even if the network drops, even if the server restarts, money must move exactly once.

Building a payment system taught me something beyond technology. It taught me the weight of responsibility. This code represents someone's salary, a founder's operating budget, a grandmother's gift for her grandchild. When bugs happen, trust collapses. That's why payment systems are hard.

Payments Aren't Simple API Calls

At first, I thought: whether it's Stripe or Toss Payments, can't I just use the SDK? Read the docs, call the charge() function, done?

No. Payments are a state machine. An order is created, a payment intent is formed, a charge happens, it's confirmed, and sometimes it's refunded. Each step can fail, and each failure needs different handling.

// My naive initial code
async function processPayment(orderId: string, amount: number) {
  const result = await paymentClient.charge({
    amount,
    orderId,
  });

  if (result.success) {
    await db.updateOrder(orderId, { status: 'paid' });
  }

  return result;
}

Counting the problems in this code, I found at least five:

1. Calling it twice with the same orderId charges twice
2. If charge() succeeds but updateOrder() fails? Money is gone but order status is unpaid
3. Network timeout and no response? No idea if payment went through
4. Payment failures have different reasons (insufficient funds, blocked card, limit exceeded) but all handled identically
5. What if I need to refund?

Payment systems aren't simple CRUD. Like a conductor leading an orchestra, you must coordinate multiple systems, ensuring each instrument (orders, inventory, payment provider, notifications) plays at the exact right moment.

Idempotency Keys: Safe Even When Sent Multiple Times

The solution to duplicate charges was idempotency. It's a math term, but simply put: "doing the same operation multiple times produces the same result as doing it once."

In payments, this is implemented with idempotency keys. Each payment request gets a unique key, and if another request comes with the same key, instead of charging again, you return the previous result.

// Payment flow with idempotency
async function createPayment(orderId: string, amount: number) {
  // Generate idempotency key based on order ID
  const idempotencyKey = `payment_${orderId}_${Date.now()}`;

  // First create payment intent in DB
  const paymentIntent = await db.createPaymentIntent({
    orderId,
    amount,
    idempotencyKey,
    status: 'pending',
  });

  // Check if already processed
  const existing = await db.findPaymentByIdempotencyKey(idempotencyKey);
  if (existing) {
    return existing; // Duplicate request returns existing result
  }

  try {
    // Actual payment provider API call
    const result = await paymentClient.charge({
      amount,
      idempotencyKey, // Both Stripe and Toss support this
      metadata: { orderId, paymentIntentId: paymentIntent.id },
    });

    // Update status on success
    await db.updatePaymentIntent(paymentIntent.id, {
      status: 'processing',
      externalId: result.id,
    });

    return result;
  } catch (error) {
    // Record even on failure
    await db.updatePaymentIntent(paymentIntent.id, {
      status: 'failed',
      errorMessage: error.message,
    });
    throw error;
  }
}

Idempotency keys are like receipt numbers. You order at a café and get a receipt. The coffee doesn't come, so you go back to the counter. Showing the receipt doesn't make them prepare the same order twice. They tell you it's already being made, or give you the finished coffee. Money is collected only once.

Payment State Machine: Track Every Transition

Payments go through multiple states. Each transition needs clear definitions of what can happen and where failures can occur.

type PaymentStatus =
  | 'pending'      // Payment intent created
  | 'processing'   // Request sent to payment provider
  | 'requires_action' // Additional auth needed (3D Secure, etc.)
  | 'completed'    // Payment completed
  | 'failed'       // Payment failed
  | 'refunding'    // Refund in progress
  | 'refunded'     // Refund completed
  | 'partial_refunded'; // Partial refund

interface PaymentStateMachine {
  current: PaymentStatus;
  allowedTransitions: Record<PaymentStatus, PaymentStatus[]>;
}

const paymentStateMachine: PaymentStateMachine['allowedTransitions'] = {
  pending: ['processing', 'failed'],
  processing: ['requires_action', 'completed', 'failed'],
  requires_action: ['processing', 'failed'],
  completed: ['refunding'],
  failed: ['pending'], // Allow retry
  refunding: ['refunded', 'partial_refunded', 'failed'],
  refunded: [], // Terminal state
  partial_refunded: ['refunding'], // Additional refunds possible
};

function canTransition(from: PaymentStatus, to: PaymentStatus): boolean {
  return paymentStateMachine[from].includes(to);
}

With a clear state machine, what needs to be recorded also became obvious. Log every state transition as an event:

interface PaymentEvent {
  id: string;
  paymentId: string;
  type: 'status_changed' | 'webhook_received' | 'refund_requested';
  fromStatus: PaymentStatus | null;
  toStatus: PaymentStatus;
  timestamp: Date;
  metadata: Record<string, any>;
  userId?: string;
}

// Always record events on status changes
async function transitionPaymentStatus(
  paymentId: string,
  toStatus: PaymentStatus,
  metadata: Record<string, any> = {}
) {
  const payment = await db.getPayment(paymentId);

  if (!canTransition(payment.status, toStatus)) {
    throw new Error(
      `Invalid transition: ${payment.status} -> ${toStatus}`
    );
  }

  await db.transaction(async (tx) => {
    // Update status
    await tx.updatePayment(paymentId, { status: toStatus });

    // Record event
    await tx.createPaymentEvent({
      paymentId,
      type: 'status_changed',
      fromStatus: payment.status,
      toStatus,
      timestamp: new Date(),
      metadata,
    });
  });
}

This is the airplane's black box. When something goes wrong, you can precisely reconstruct what happened at what moment. When a user says "I paid but it didn't work," you can look at the event log and know exactly where it got stuck.

Webhooks and Retries: How Payment Providers Talk to Us

Payments are asynchronous. Card issuer approval might be slow, 3D Secure authentication takes time. Payment providers notify results via webhooks.

The problem is webhooks aren't reliable. Networks can drop, our server can restart, and the same webhook can arrive multiple times.

// Webhook handler: idempotency is key
async function handlePaymentWebhook(
  payload: WebhookPayload,
  signature: string
) {
  // 1. Verify signature (critical! prevents forgery)
  const isValid = verifyWebhookSignature(payload, signature);
  if (!isValid) {
    throw new Error('Invalid webhook signature');
  }

  // 2. Check duplicates by webhook event ID
  const eventId = payload.id;
  const existing = await db.findWebhookEvent(eventId);
  if (existing) {
    // Already processed: return 200 OK (stops retries)
    return { status: 'already_processed' };
  }

  // 3. Record webhook event (ensures idempotency)
  await db.createWebhookEvent({
    id: eventId,
    type: payload.type,
    data: payload.data,
    processedAt: new Date(),
  });

  // 4. Handle by event type
  switch (payload.type) {
    case 'payment.completed':
      await handlePaymentCompleted(payload.data);
      break;
    case 'payment.failed':
      await handlePaymentFailed(payload.data);
      break;
    case 'refund.completed':
      await handleRefundCompleted(payload.data);
      break;
  }

  return { status: 'processed' };
}

async function handlePaymentCompleted(data: any) {
  const paymentId = data.paymentId;

  await db.transaction(async (tx) => {
    // Update payment status
    await transitionPaymentStatus(paymentId, 'completed', {
      source: 'webhook',
      externalId: data.id,
    });

    // Complete order
    const payment = await tx.getPayment(paymentId);
    await tx.updateOrder(payment.orderId, {
      status: 'paid',
      paidAt: new Date(),
    });

    // Deduct inventory, send emails, etc.
    await fulfillOrder(payment.orderId);
  });
}

Webhook retry logic matters too. Stripe retries for up to 3 days on failure. We can implement similarly:

// Queue for webhook retries
async function enqueueWebhookRetry(
  webhookUrl: string,
  payload: any,
  attempt: number = 0
) {
  const maxAttempts = 5;
  const backoffMs = Math.pow(2, attempt) * 1000; // Exponential backoff

  if (attempt >= maxAttempts) {
    // Final failure: send alert
    await notifyWebhookFailure(webhookUrl, payload);
    return;
  }

  setTimeout(async () => {
    try {
      await sendWebhook(webhookUrl, payload);
    } catch (error) {
      // Retry on failure
      await enqueueWebhookRetry(webhookUrl, payload, attempt + 1);
    }
  }, backoffMs);
}

Webhooks are like mail delivery. You send a letter (event) but nobody's home (server down), so they come back later. After several attempts, they hold it at the post office (Dead Letter Queue). And crucially, even if you receive the same letter multiple times, you must process it as if read only once (idempotency).

Refunds and Partial Refunds: Returning Money Isn't Easy Either

Refunds can be more complex than payments. You need to consider full refunds, partial refunds, refund fees, and refund deadlines.

interface RefundRequest {
  paymentId: string;
  amount?: number; // undefined = full refund
  reason: 'requested_by_customer' | 'fraudulent' | 'duplicate' | 'other';
  metadata?: Record<string, any>;
}

async function refundPayment(request: RefundRequest) {
  const payment = await db.getPayment(request.paymentId);

  // Check refundable status
  if (payment.status !== 'completed') {
    throw new Error('Only completed payments can be refunded');
  }

  // Validate refund amount
  const refundAmount = request.amount ?? payment.amount;
  const alreadyRefunded = await db.getTotalRefunded(request.paymentId);

  if (alreadyRefunded + refundAmount > payment.amount) {
    throw new Error('Refund amount exceeds payment amount');
  }

  // Create refund intent
  const refund = await db.createRefund({
    paymentId: request.paymentId,
    amount: refundAmount,
    reason: request.reason,
    status: 'pending',
  });

  try {
    // Call payment provider API
    const result = await paymentClient.refund({
      paymentId: payment.externalId,
      amount: refundAmount,
      reason: request.reason,
      idempotencyKey: `refund_${refund.id}`,
    });

    // Change to refunding state
    await transitionPaymentStatus(
      request.paymentId,
      refundAmount === payment.amount ? 'refunding' : 'partial_refunded',
      { refundId: refund.id }
    );

    await db.updateRefund(refund.id, {
      status: 'processing',
      externalId: result.id,
    });

    return refund;
  } catch (error) {
    await db.updateRefund(refund.id, {
      status: 'failed',
      errorMessage: error.message,
    });
    throw error;
  }
}

Refunds are also processed asynchronously, with results delivered via webhooks. And importantly, refunds also need reconciliation.

Reconciliation: Does Our Record Match Real Money?

The scariest thing in payment systems is "our DB says payment succeeded, but money never actually came in" or vice versa.

Reconciliation is the process of periodically comparing our DB records with the payment provider's:

async function reconcilePayments(date: Date) {
  // 1. Get our payment records for the date
  const ourPayments = await db.getPaymentsByDate(date);

  // 2. Get payment provider records
  const theirPayments = await paymentClient.listPayments({
    created: { gte: date, lt: addDays(date, 1) },
  });

  // 3. Match
  const ourIds = new Set(ourPayments.map(p => p.externalId));
  const theirIds = new Set(theirPayments.map(p => p.id));

  // Only in our DB (not in payment provider)
  const onlyInOurDB = ourPayments.filter(
    p => !theirIds.has(p.externalId)
  );

  // Only in payment provider (not in our DB)
  const onlyInPaymentProvider = theirPayments.filter(
    p => !ourIds.has(p.id)
  );

  // 4. Report discrepancies
  const report = {
    date,
    totalOurs: ourPayments.length,
    totalTheirs: theirPayments.length,
    mismatches: {
      onlyInOurDB,
      onlyInPaymentProvider,
    },
  };

  // 5. Send alerts
  if (onlyInOurDB.length > 0 || onlyInPaymentProvider.length > 0) {
    await alertFinanceTeam(report);
  }

  return report;
}

// Daily reconciliation at midnight for previous day
cron.schedule('0 0 * * *', async () => {
  const yesterday = subDays(new Date(), 1);
  await reconcilePayments(yesterday);
});

Reconciliation is like bank settlement. Checking if the ledger balance matches the actual cash in the vault. If they don't match, you need to find where money leaked or records were missed.

PCI DSS: Never Store Card Information Ourselves

PCI DSS (Payment Card Industry Data Security Standard) is the security standard all systems handling card payments must follow. The core is simple: don't store card numbers on our server.

Instead, use tokenization:

// Frontend sends card info directly to payment provider
// (doesn't go through our server)
const stripe = Stripe('pk_live_...');
const cardElement = elements.create('card');

// Generate token
const { token } = await stripe.createToken(cardElement);

// Only send token to our server
const response = await fetch('/api/payments', {
  method: 'POST',
  body: JSON.stringify({
    orderId: 'order_123',
    paymentToken: token.id, // Token, not card number
  }),
});

The server never sees the card number. It receives only the token and passes it to the payment provider:

async function chargeWithToken(orderId: string, token: string) {
  const order = await db.getOrder(orderId);

  const result = await paymentClient.charge({
    amount: order.amount,
    source: token, // Use token
    metadata: { orderId },
  });

  // Store only payment result (no card info)
  await db.createPayment({
    orderId,
    amount: order.amount,
    externalId: result.id,
    last4: result.card.last4, // Only last 4 digits
    brand: result.card.brand, // Visa, MasterCard, etc.
  });
}

This is like hiring a designated driver. We don't handle the car (card info) ourselves. We leave it to the professional driver (payment provider), and we just say "take me from A to B (process this payment)."

What I Really Learned: Responsibility Over Code

Building a payment system taught me a lot of technology. Idempotency, state machines, webhooks, reconciliation. But what I really learned was the weight of responsibility.

The user who got charged twice for clicking a button. The customer who sent an angry email because the refund was delayed. The teammate who stayed up for nights because reconciliation didn't match. All of this was because of my code.

Code that moves money is different. You write more tests. You log more details. You think harder about edge cases. Not "this should be good enough," but "is this truly safe?"

Payment systems aren't a technology problem. They're a trust problem. Users trust us enough to enter their card numbers. Protecting that trust is the developer's job. That's why payment code is heavy. It must be heavy.
